Vibration Meter
- 183 x 67 x 30 mm
General Description
Vibration Meter – 183 x 67 x 30 mm
The vibration meter has a total size of 183 x 67 x 30 mm. The acceleration measurement range is 0.1 – 199.9 meters/sq, second, the velocity measurement range is 0.1 – 199.9 mm/s, and the displacement measurement range is 0.001 – 1.999 m P-P.
Function
The vibration meter uses a vibration sensor called an accelerometer to measure the velocity, acceleration, and displacement of a designated area in order to determine vibration level, which is then displayed on the LCD screen. There are several options for vibration analysis. The unit is powered by a 9V battery.
Applications
The vibration meter is ideal for mechanical and industrial settings to measure the vibrations associated with various kinds of industrial machinery in troubleshooting and efficiency testing.
Technical Details
| Acceleration Measurement Range: | 0.1~199.9 m/sq second |
|---|---|
| Velocity Measurement Range: | 0.1~199.9 mm/s rms |
| Displacement Measurement Range: | 0.001~1.999 m P-P |
| Measuring Accuracy: | 5% |
| Measurement Frequency Range of Acceleration: | 10 Hz~1 KHz (LO), 1KHz~15KHz (HI) |
| Measurement Frequency Range of Velocity: | 10 Hz~1 KHz (LO) |
| Measurement Frequency Range of Displacement: | 10 Hz~1 KHz (LO) |
| LCD Display: | 3.5 Digits |
| Operating Temperature: | 0~40'C |
| Power: | 9V Battery |
| Unit Size: | 183 x 67 x 30 mm |
| Brand: | Deelat Industrial |
