Pneumatic Air Cutter (0.9 mm)
Product Video
General Description
Pneumatic Air Cutter (0.9 mm)
The pneumatic shear has a cutting capacity on stainless steel of 0.9 mm. The color of the unit is orange, and it has an air consumption of 3 CFM.
Function
The pneumatic air cutter is fed high speed air from the bottom of the unit, which powers the cutting head. When a material that needs cutting is positioned within the head, manually squeezing the handle on the nipper activates the shearing action of the blade. The nipper can also be used for crimping, bending, and grabbing according to specific needs.
Applications
The air powered pneumatic shear is ideal for environments where copper, iron, and other hard materials need to be cut quickly and in large quantities, such as in construction, automotive, industrial settings.
Technical Details
| Certifications: | CE |
|---|---|
| Size: | 290 x 60 x 60 mm |
| Color: | Orange |
| Max. Opening: | 9 mm |
| Free Speed: | 2600 RPM |
| Max Pressure: | 90 PSI |
| Air Inlet: | 1/4 " |
| Hose Size: | 3/8" |
| Air Consumption: | 3 CFM |
| Weight: | 1.05 kg |
| Able to Cut: | 0.9 mm Stainless Steel |
| Brand: | Deelat Industrial |
Do you have a question about this product?
Deep Well Pump (Submersible) - 862' 10 11/32" Max. Head Height - 1848 GPH The deep well pump is submersible, and is three phase with 5.5 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Replacement Blade for Pneumatic Air Cutter (2.0 mm, 2.6 mm, D1158643) The replacement blade for the pneumatic shear has a cutting capacity of 2.0 mm and 2.6 mm and is intended for use with product D1158643. Function The replacement blade is...
Pneumatic Air Cutter (0.9 mm) The pneumatic shear has a cutting capacity on stainless steel of 0.9 mm. The color of the unit is orange, and it has an air consumption of 3 CFM. Function The pneumatic air cutter is fed high speed air from the...
Pneumatic Air Cutter (1.2 mm - 1.6 mm - 5 mm) The pneumatic shear has a cutting capacity of 1.2 mm on stainless steel, 1.6 mm on copper, and 5 mm on iron plate. It has a working pressure of 90 PSI and an air inlet of 1/4". Function The...
Air Curtain – 220V – 47-1/4" Door Width – 120W - Effective Height 9' 10-1/8" - 120 Series The air curtain is 220V and has a door width of 47-1/4". The unit is 120W and is part of the 120 series. Function The air curtain sends a stream of air...
Replacement Blade for Pneumatic Air Cutter (0.5 mm, 1 mm, D1151446) The replacement blade for the pneumatic shear has a cutting capacity on iron wire of 0.5 mm and on copper wire of 1 mm and is intended for use with product D1151446. Function...
Pneumatic Air Cutter (2.8 mm, 3.3 mm) The pneumatic shear has a cutting capacity on iron wire of 2.8 mm and on copper wire of 3.3 mm. It has an air consumption of 230 cubic cm/min. Function The pneumatic air cutter is fed high speed air from...
Pneumatic Air Cutter for Plastics (5.0 mm, 7.0 mm) The pneumatic shear has a cutting capacity on hard plastic of 5.0 mm and on soft plastic of 7.0 mm. It uses an FD-6 blade and has an air consumption of 112 l/min (4 CFM). Function The...
Pneumatic Air Cutter (0.5 mm, 1 mm) The pneumatic shear has a cutting capacity on iron wire of 0.5 mm and on copper wire of 1 mm. It has an air inlet of P.T 1/4" and has an air consumption of 28 L/min. Function The pneumatic air cutter is fed...
Pneumatic Air Cutter (1.0 mm, 1.6 mm) The pneumatic shear has a cutting capacity on iron wire of 1.0 mm and on copper wire of 1.6 mm. The air inlet is P.T 1/4" and the unit has an air consumption of 230 cubic cm/min. Function The pneumatic...
Pneumatic Air Cutter (2.0 mm, 2.6 mm) The pneumatic shear has a cutting capacity on iron wire of 2.0 mm and on copper wire of 2.6 mm. It uses an S5 blade and has an air consumption of 230 cubic cm/min. Function The pneumatic air cutter is fed...
Do you make carbide tooling for them?
Hi Dave, thanks for your question. We currently do not have carbide tooling for the Pneumatic Shear and Air Nipper, but please check back with us as we are constantly adding new products. If you have any other questions or concerns please do not hesitate to contact us.
Do you have a cutter that will cut 4mm wires
This pneumatic air cutter is capable of cutting up to 3.3mm copper wire or 2.8mm iron wire, so it would depend on the material of the wire you are using. Please contact our customer service for more information so we can better advise you.
Would it cut 8 AWG tinned copper wire?
Hi Anyurith, thank your for your question. This cutter has blades specifically designed to cut through plastic, thus cutting copper wire wouldn't be recommended. Please see your question for D1775585 -- that is a better cutter for your application. If you have any other questions or concerns please do not hesitate to contact us.
What is the cutting diameter of this cutter? Will it cut 1"-1.5"?
Hello Gaby, thank you for your question. The maximum cutting diameter for this pneumatic cutter is .75 inches. That is also the maximum width of the cutting mouth as well. To cut 1"-1.5" we recommend using the manual cutter which is SKU# D1155345. If you have any other question or concerns please contact us at 1-888-667-5776
What size is the air fitting on the end of these SKU #D1158644 pneumatic shears?
Hello Alli, thank you for your question. The air fitting on the end of our pneumatic shears SKU# D1158644 is 8mm. If you have any other questions or concerns please do not hesitate to contact our customer support team.
Would it cut 8 AWG tinned copper wire?
Hi Anyurith, thanks for your question. This cutter can cut through copper wire that is 3.3 millimeters in diameter, which is roughly the same size as 8 AWG tinned copper wire. If you have any other questions or concerns please do not hesitate to contact us.
Why is this cutter a lot more expensive than others made in Taiwan and is it made especially for DEELAT what makes it better than the other ones made in Taiwan that selling for less I need to cut 2 mm HH brass square rod?
Hello Jennifer, thank you for your question. We cannot speak for the other tools you have seen online but we certainly can stand behind our Deelat branded tools. Our pneumatic shear and air cutters are hand assembled and thoroughly tested. They are also backed by our industry leading warranty. We also stalk all our products locally which many of the other tools you are seeing can have 1 or even 2 month turnaround. If you have any other questions or concerns please do not hesitate to contact our customer support team.
I work at a scrap yard and one of my duties is to process cars. Would one of these tools work for cutting the straps off the gas tanks?
No, our pneumatic air cutters would not work for this purpose.
What is the operating PSI for this air nipper?
Hello Russ, thank you for your question. The operating pressure is .4-.5 MPA this translates to about 58-73 PSI. If you have any other questions please do not hesitate to contact our customer support team.
Can these be used for electronic applications? We are looking for a tool to cut small transformer leads on printed circuit boards. Leads are about 1.2mm/.05".
Hi Andy, thanks for your interest. We can only recommend using this pneumatic cutter to cut copper wire or plastic. If you would like to call our sales team at 1-888-667-5776, they can help you select the correct pneumatic cutter for electronic applications.
How fast is the mechanism on this cutter? Does it snap closed or does it slowly close?
Since our cutters are pneumatic, the mechanism is fast, and it will snap closed when you press the handle.
I would like to know if this will cut 28 gauge pole barn metal which has ribbing in it of course.
Hello Dale, thank you for your question. This pneumatic shear and air cutter has a max opening of 9mm which is about .36 inches. If the pole has a diameter greater than this it will not cut it.
how long will they last cutting #6 zinc coated screws
Hello David, thanks for your question. This product can only be used to cut copper and plastic. We do not recommend using it to cut zinc coated screws. If you have any other questions or concerns please do not hesitate to contact us.
Looking for air nippers capable of cutting up to 10 awg galvanized wire for making crab traps. Any suggestions?
Hi Buddy, thanks for the question. Yes, this air nipper is capable of cutting 10 AWG wire, which has a diameter of 2.6 millimeters. These shears can cut copper wire with diameters of up to 3.3 mm and iron wire with diameters of up to 2.8 mm. If you need assistance with your purchase, please call our sales team at 1-888-667-5776 or email at sales@deelat.com!
Will this unit cut 0.7mm sheet metal that is 1&1/4" wide?
Hello Frank, thank you for your question. Yes this cutter will certainly cut 0.7mm sheet metal. You should have absolutely no issues using this cutter and should perform as intended.
What is the weight of D1151446?
Thank you for your question, Valentin. The weight of this air nipper is 7 ounces/0.2 kilograms. If you have any other questions or concerns please do not hesitate to contact us.
How much does this product weigh?
Hi David, thanks for your question. This air nipper weighs 0.25 kg or 9 ounces. If you need assistance with your purchase, please call our sales team at 1-888-667-5776 or email at sales@deelat.com!
Can this tool be used to cut tack wells on a core support
Hello Pete, thank you for your question. Unfortunately this pneumatic cutter will not be suitable to cut tack wells. We currently do not have any cutter that will work for your application. Please cvheck back with us in a month or so as we are constantly adding products to our inventory.
Do you have anything pneumatic that will cut 1/4 inch plywood or lathe?
Hi Charles, thanks for your question. Unfortunately, we do not have anything pneumatic that will cut 1/4 inch plywood or lathe. We do sell #D1158644 that will cut 5mm hard plastic and 7mm soft plastic. If you have any other questions or concerns please do not hesitate to contact us.
Can this tool cut a 12 gauge lobster trap wire?
Hi Anthony, thanks for your question. A 12 gauge wire has a diameter of over 2 millimeters, therefore this tool wouldn't be adequate to cut your lobster trap wire. We recommend using a different pair of cutters, SKU #D1158643, for your application. If you need assistance with your purchase, please call our sales team at 1-888-667-5776 or email at sales@deelat.com!
What gauge mild steel will this cut?
Hello William, thank you for your question. This Pneumatic Shear and Air Cutter has the ability to cut stainless steel up to 1mm thick. So any mild steel below 1mm should be suitable for this air nipper.
What brand is this product? where was it made?
Thanks for your interest in our pneumatic products, Anyurith. The brand is Deelat Industrial and it was made in China. If you have any other questions or concerns please do not hesitate to contact us.
Can we use this product to trim fiberglass that is 4mm thick?
We have not tried using the pneumatic air cutter on fiberglass, as it is meant for other hard and soft plastics, so proceed with caution if you wish to do this.
