Threaded Flange – Nominal Pipe Size 5” – Class 150 - Raised Face – Stainless Steel – F316/316L
The screw-on flange's nominal pipe size is 5” with a total diameter of 10”. It has a pressure class rating of 150 and has 8 bolt holes. It is made of AMSE B 16.5 (steel) and comes in a thickness of 1.4425”.
The threaded flange is very similar in function to the slip-on flange however it allows for a pipe to be screwed in without the need for welding and therefore has a bore that is larger than the outer diameter of the pipe. The threaded flange is used in low pressure systems that are run in normal temperatures.
The screw-on flange is used in pipeline applications where liquid or gas is transported from one location to another. The pipe used must be of a certain thickness to be used with this flange. Best used in applications where welding is dangerous.
Download Spec sheetSKU #D1149907
|Nominal Pipe Size:||5"|
|Number of Bolts:||8|
|Overall Diameter:||10 inch|
|Overall Thickness:||1.4425 inch|
|Bolt Hole Diameter:||0.88 inch|
|Bolt Circle Diameter:||8.5 inch|
