Threaded Flange
- Nominal Pipe Size 2” - Class 300 - Raised Face - Stainless Steel - F304/304L
Product Video
General Description
Threaded Flange – Nominal Pipe Size 2” – Class 300 - Raised Face – Stainless Steel – F304/304L
The screw-on flange's nominal pipe size is 2” with a total diameter of 6.5”. It has a pressure class rating of 300 and has 8 bolt holes. It is made of AMSE B 16.5 (steel) and comes in a thickness of 1.3125”.
Function
The threaded flange is very similar in function to the slip-on flange however it allows for a pipe to be screwed in without the need for welding and therefore has a bore that is larger than the outer diameter of the pipe. The threaded flange is used in low pressure systems that are run in normal temperatures.
Applications
The screw-on flange is used in pipeline applications where liquid or gas is transported from one location to another. The pipe used must be of a certain thickness to be used with this flange. Best used in applications where welding is dangerous.
Technical Details
| Type: | NPT Threaded |
|---|---|
| Nominal Pipe Size: | 2" |
| Class: | 300 |
| Weight: | 7 lb |
| Number of Bolts: | 8 |
| Overall Diameter: | 6.5 inch |
| Overall Thickness: | 1.3125 inch |
| Bolt Hole Diameter: | 0.75 inch |
| Bolt Circle Diameter: | 5 inch |
| Standard: | AMSE B16.5 |
| Brand: | Deelat Industrial |
Do you have a question about this product?
Threaded Flange – Nominal Pipe Size 6” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 6” with a total diameter of 11”. It has a pressure class rating of 150 and has 8 bolt holes. It is made of...
Threaded Flange – Nominal Pipe Size 1/2” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 1/2” with a total diameter of 3.5”. It has a pressure class rating of 150 and has 4 bolt holes. It is...
PVC Flexible Duct – 6" (Diameter) * 25ft (Length) The 6” in diameter PVC duct has a length of 25 feet and is made out of a PVC material. It is able to endure temperatures between -4°F and +176°F. It is built with a steel wire helix frame....
Industrial Floor Scale - 6614lbs - 31 1/2" W x 31 1/2" L - Digital - Low Profile The industrial floor scale has a digital display, is low profile, and has a steel construction. The size of the scale is 31 1/2" wide by 31 1/2" long, and the...
Threaded Flange – Nominal Pipe Size 1-1/4” – Class 300 - Raised Face – Stainless Steel – F304/304L The screw-on flange's nominal pipe size is 1-1/4” with a total diameter of 5.25”. It has a pressure class rating of 300 and has 4 bolt holes. It...
Threaded Flange – Nominal Pipe Size 12” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 12” with a total diameter of 19”. It has a pressure class rating of 150 and has 12 bolt holes. It is made...
Threaded Flange – Nominal Pipe Size 3” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 3” with a total diameter of 7.5”. It has a pressure class rating of 150 and has 4 bolt holes. It is made of...
Threaded Flange – Nominal Pipe Size 3/4” – Class 300 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 3/4” with a total diameter of 4.62”. It has a pressure class rating of 150 and has 4 bolt holes. It is...
Threaded Flange – Nominal Pipe Size 3/4” – Class 150 - Raised Face – Stainless Steel – F304/304L The screw-on flange's nominal pipe size is 3/4” with a total diameter of 3.88”. It has a pressure class rating of 150 and has 4 bolt holes. It is...
Threaded Flange – Nominal Pipe Size 10” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 10” with a total diameter of 16”. It has a pressure class rating of 150 and has 12 bolt holes. It is made...
Threaded Flange – Nominal Pipe Size 8” – Class 150 - Raised Face – Stainless Steel – F316/316L The screw-on flange's nominal pipe size is 8” with a total diameter of 13.5”. It has a pressure class rating of 150 and has 8 bolt holes. It is made...
Threaded Flange – Nominal Pipe Size 2” – Class 300 - Raised Face – Stainless Steel – F304/304L The screw-on flange's nominal pipe size is 2” with a total diameter of 6.5”. It has a pressure class rating of 300 and has 8 bolt holes. It is made of...
please confirm the threaded hole for the 1-1/2" threaded flange will accept a 1-1/2" NPT pipe.
Hello Brian, thank you for your question. Yes this will accept an 1 1/2" NPT threaded pipe. Please do not hesitate to contact our customer support team if you have any other questions or concerns.
Is this available as a 6 bolt flange?
Hello George, thank you for your question. Unfortunately this threaded flange only comes with a 4 bolt pattern. It is not available in any other bolt pattern.
Does this meet American Iron and Steel (AIS) requirements?
Hello Billy, thank you for your question. All our stainless steel flanges meet the ASTM international standard. If you have any other question please feel free to contact our customer support staff.
