Blind Flange- Nominal Pipe Size 8" - Class 900
Open For Business & Shipping Daily During COVID-19
Blind Flange - Nominal Pipe Size 8" - Class 900 - Stainless Steel
This solid flange's nominal pipe size is 8” with a total diameter of 18.5”. It has a pressure class rating of 900 and has 12 bolt holes. It is made of AMSE B 16.5 (steel) and comes in a thickness of 2.5”.
The blind flange is a flange without a bore and is used to seal off pipe ends. The flanges can be used in systems that are operational or in expansion systems that are not yet operational. They allow easy access to the line and can be sealed and re-opened.
This solid flange is used in pipeline applications where liquid or gas is transported from one location to another.
Download Spec sheetSKU #D1146488
|Nominal Pipe Size:||8"|
|Number of Bolt Holes:||12|
|Bolt Hole Diameter:||1.5"|
|Bolt Circle Diameter:||15.5"|
|Standard:||AMSE B 16.5|
