Blind Flange- Nominal Pipe Size 48" - Class 300
Open For Business & Shipping Daily During COVID-19
Blind Flange - Nominal Pipe Size 48" - Class 300
This solid flange's nominal pipe size is 48” with a total diameter of 57.75”. It has a pressure class rating of 300 and has 32 bolt holes. It is made of AMSE B 16.5 (steel) and comes in a thickness of 5.25”.
The blind flange is a flange without a bore and is used to seal off pipe ends. The flanges can be used in systems that are operational or in expansion systems that are not yet operational. They allow easy access to the line and can be sealed and re-opened.
This solid flange is used in pipeline applications where liquid or gas is transported from one location to another.
Download Spec sheetSKU #D1146338
|Size:||Nominal Pipe Size 48"|
|Number of Bolt Holes:||32|
|Bolt Hole Diameter:||2"|
|Bolt Circle Diameter:||54"|
|Standard:||AMSE B 16.47 A|
