Eyewash Station
- Double Head - 304 Stainless Steel
General Description
Eyewash Station - Double Head – 304 Stainless Steel
The eyewash station features a double head. The body metal is 304 stainless steel, and the spray head that presses against the eye is made out of soft rubber. The maximum working pressure is 6 bar.
Function
The eye washing station is mounted to a surface and connected to a water line. There is a protective dust cap on the unit, which needs to be removed prior to use. Water flows out of the eyewash faucet and into the eye of an affected person, flushing out harmful agents.
Applications
The eyewash faucet is ideal for laboratories in medical or educational settings and for other environments where potentially harmful chemicals are in use.
Technical Details
| Certifications: | TUV, CE |
|---|---|
| Size: | 19 1/2" x 10 5/8" x 69 11/16" |
| Body: | 304 Stainless Steel |
| Coating: | High gloss epoxy powder, resistant to chemicals, UV fading and heat |
| Spray Head: | Soft rubber, softened water spray for eye protection |
| Dust Cap: | PP, removed automatically when eye wash is operated |
| Max. Working Pressure: | 6Bar |
| Min. Working Pressure: | 4bar/58psi/400kPa |
| Color: | Red |
| Brand: | Deelat Industrial |
Do you have a question about this product?
Eyewash Station – Bench-Top - Double Head - Brass The eyewash station is a bench-top model and features a double head. The parent metal is brass, and the rubber cup that presses against the eye is made out of silica gel. The maximum working...
Eyewash Station – Single Head - Brass The eyewash station features a single head. The parent metal is brass, and the spray head that presses against the eye is made out of soft water. The maximum working pressure is 6 bar. Function The eye...
Eyewash Station - Double Head – 304 Stainless Steel The eyewash station features a double head. The body metal is 304 stainless steel, and the spray head that presses against the eye is made out of soft rubber. The maximum working pressure is 6...
Eyewash Station - Double Head - Brass The eyewash station features a double head. The parent metal is brass with a high gloss epoxy powder, and the rubber cup that presses against the eye is made out of silica gel. The maximum working pressure...
Emergency Eye Wash Station - Double Head - 304 Stainless Steel The eyewash station features a double head. The body is 304 stainless steel, and the spray head that presses against the eye is made out of soft rubber. The maximum working pressure...
Emergency Shower and Eyewash Station- Red The eyewash station features an emergency shower alongside an eye washing station. This eye washer features a double head, and the color of the unit is red. The body metal is stainless steel, and the...
Portable Eye Wash Station - Single Head The portable eye washer station features a single head. The spray head material is ABS. The volume is 9.2 gallons and it is equipped with 2 water purifier filters. Function The portable eye washer has a...
Eyewash Station – Desk-Mounted - Single Head- Brass The eyewash station is a desk-mounted model and features a single head. The material is brass, and the sprayer head material is soft rubber. The maximum working pressure is 7 bar. Function...
Emergency Shower - Stainless Steel The emergency shower is made out of stainless steel and has a maximum working pressure of 7 bar. Function The emergency shower and eye washing station is mounted to the floor and connected to a water line. A...
Duct Clamp – Steel - Size 18” The duct clamp is made out of steel and the size is 18”. Function The screw clamp employs a stainless steel band which wraps around ducting as it makes a connection with a barb or nipple. The screw on the outer...
Emergency Eye Wash Station – Bench-Top - Single Head - Brass The eyewash station is a bench-top model and features a single head. The parent metal is brass, and the rubber cup that presses against the eye is made out of silica gel. The maximum...
PVC Flexible Duct – 4" (Diameter) * 25ft (Length) The 4” in diameter PVC duct has a length of 25 feet and is made out of a PVC material. It is able to endure temperatures between -4°F and +176°F. It is built with a steel wire helix frame....
Does the emergency shower and double outlet eyewash station meet Australian Standards?
Hi Kerry, thanks for your interest in our eyewash stations. Unfortunately, the fans do not have Australian certifications. However, they do have CE and TUV certifications. If you have any other questions or concerns please do not hesitate to contact us.
Would like to know if there is any problem with hooking up to our city water which has incoming water to be at levels of 2.0 free chlorine and 3.9 total chlorine respectively. And if we were to purchase what hookups would we need to purchase with it?
This eye wash can be used with water containing chlorine particles as it is stainless steel and will not corrode. However, we suggest contacting your local water supply company to make sure it is safe to use to wash your eyes with. The eye wash has a standard water hook up and nothing additional needs to be purchased. It should connect direct to your tap or water source.
how is this unit plumbed. is the hose easily connected to a tap
Hello Alan, thank you for your question. This eye washer is designed to be wall or desk mounted and plumbed through the wall. The washer has a standard water connection and is easily installed to a tap or water source.
Can this item be used continuously for at least 15 minutes (OSHA Standard) or more, and do you ship to Alaska?
Hello Jessica, thank you for your question. Yes, our portable eye washer can be used continuously for 15 minutes straight. Yes we are certainly able to ship anywhere in Alaska. We can ship with FedEx or USPS.
What is the flow rate?
Hello Bryan, thank you for your question. The flow rate for this eyewash is a little bit more than 3 gallons per minute (12Lpm). If you have any other questions or concerns please do not hesitate to contact our customer support team.
