Wall Heating Panel
- 23.6 x 27.6 x .87" - 300W, 110V - Glass
Product Video
General Description
Wall Heating Panel - 23.6 x 27.6 x .87" - 300W, 110V - Glass
The radiant electric wall heating panel has dimensions of 23.6 x 27.6 x .87" and is 300W. The unit is 110V with a carbon crystal heating element and frameless with the front surface made out of black glass. The surface temperature reaches 176 - 221°F.
Function
The radiant heat panel has a heating element that transfers heat to a room by infrared radiation and is fortified with an aluminum sheet that reflects heat into the room. The unit is installed on a wall or ceiling using anchored screws and plugs into a wall outlet using a standard 6.6' cable.
Applications
The radiant panel is intended for indoor use in bedrooms, offices, basements, or any area inside a home that stays cold and needs to be efficiently heated.
Technical Details
| Size: | 23.6 x 27.6 x .87" |
|---|---|
| Voltage: | 110 V |
| Power: | 320 W |
| Thickness: | .87" |
| Weight: | 14.2 lbs |
| Heat Capacity: | 1.1 W/ ft3 |
| Approximate Heating Area: | 43 ft² |
| Heating Element: | Carbon Crystal |
| Surface Temperature: | 176 - 221°F |
| Electric Conversion Efficiency: | 98% |
| Life Expectancy: | ~100,000 H |
| Front Surface: | Black Glass |
| Frame: | Frameless |
| Back Material: | Aluminum Sheet |
| Ingress Protection Ration: | IP54 (Standard) |
Do you have a question about this product?
Short Radius Elbow – 3A – 3/4” The short elbow pipe is a 3A standard 3/4” pipe with an angle of 90°. It is constructed out of stainless steel and features a weld connection. The wall thickness is .065”. Function The short elbow pipe is used...
Pneumatic/ Hydraulic Air Riveter Gun – 5/32”, 3/16", 15/64", 1/4" (4 mm, 4.8 mm, 6 mm, 6.4 mm) The pneumatic/ hydraulic air riveter gun has rivet capacity settings of 5/32”, 3/16”, 15/64”, ¼” and the air consumption is 50 L/min. The tool has a...
These japanese high-end cable cutters ensure an accurate and precise cut of a variety of cables including those constructed from copper and aluminum. They are ideal for use with a range of applications and are a useful addition to any toolbox,...
Industrial Floor Scale - 6614lbs - 40" W x 40" L - Digital - Low Profile The industrial floor scale has a digital display, is low profile, and has a steel construction. The size of the scale is 40" wide by 40" long, and the weight capacity is...
Caster – Double Ball Bearing, Top Plate – Heavy Duty – Iron Core PU – Dia. 3.93" The caster is a double ball bearing with a top plate and is heavy duty. The unit is constructed out of iron core polyurethane (PU) with a wheel diameter of 3.93"....
Motor Start Capacitor – 300 – 360 Microfarads - 8.5 x 3.6 x 8.5 The motor start capacitor has a microfarad rating of 300 – 360 and dimensions of 8.5 x 3.6 x 8.5. The operational temperature range is -25 – 65° Celsius, and the tolerance range is...
This tool makes installing rivet-nuts quick, easy and convenient. It features an M3 and M4 size head and an air inlet size of 1/4". It is the ideal tool for a range of industrial maintenance, construction and DIY related applications. The tool...
Centrifuge - 1700xg - Capacity 6 x 1.5mL/2.0mL / 2 x 8 x 0.2mL Vacutainers - LCD Digital Clinical The centrifuge is able to hold up to 6 containers of various numbers and sizes, including 1.5 mL/2.0 mL x 6, or 2 x 8 x 0.2 mL vacutainers. Tubes...
Non-Sparking Flat Head Screwdriver - 3mm x 50mm The non-sparking flat head screwdriver is made from an aluminum-bronze alloy. The tip of the tool is 3 mm wide and 50 mm long. The tool is beryllium free and Factory Mutual (FM) certified....
Wall Heating Panel - 23.6 x 27.6 x .87" - 300W, 110V - Glass The radiant electric wall heating panel has dimensions of 23.6 x 27.6 x .87" and is 300W. The unit is 110V with a carbon crystal heating element and frameless with the front surface...
Wall Heating Panel - 23 5/8" x 39 3/8" x 7/8" - 450W, 110V - Glass The radiant electric wall heating panel has dimensions of 23 5/8" x 39 3/8" x 7/8" and is 450W. The unit is 110V with a carbon crystal heating element and is frameless with the...
This attractive and technologically innovative door handle lock set provides full and excellent security to any doorway or property entrance. It features optional unlocking modes that can be set individually or in certain combinations according to...
What is the micron wavelength?
Hello Don, thank you for your question. The Radiant Electric Wall Heating Panel has a radiant output of about 8-10 micron wavelengths. This is ideal for comfort.
Could these be effective in heating pool water if mounted above my indoor pool? Looking for affordable alternative to solar and heat pump.
Hello Greg, thank you for your question. Unfortunately no, you cannot use these heating panels to heating pool water. They will however heat up the area around the indoor pool but not the water itself. The panels heat using a radiation method which only heats air.
