Stepper Motor

- 3-Phase - 36.88 ft lbs, 10.67" Length

Product Video

3-Phase Stepper Motor - 50N.m, 271mm Long
Open For Business & Shipping Daily During Covid-19
3 Items in Stock
Select filters above OR


View All Products

$37500 -20%
$30000
Quantity


Payment Methods

Free shipping on
orders over $400

Payment Methods
Calculate Shipping

General Description

Stepper Motor – 3-Phase - 36.88 ft lbs, 10.67" Length


The stepper motor is 3-phase with a holding torque of 36.88 ft lbs, and the overall length of the unit is 10.67". The stepper motor also has a splashproof construction.

Function
The step motor has an internal shaft attached to a gear that moves in discrete angular steps when activated by an electrical impulse. The electrical input powers a series of electromagnets that attract the gear’s teeth, which enables the motor to turn in a controlled and precise way.

Applications
The step motor is ideal for the power supply in any application where precise motor synchronization is needed, such as in the auto industry for windshield wiper motors, the medical industry for scanners and pumps, and in office machines such as copiers or printers, including 3D printers.

Technical Details

Length (in): 10.67"
Phase: 3
Holding Torque (ft lbs): 36.88
Phase Inductance (mH): 18.3
Protect Feature: Splashproof
Temperature Rise: 80 Max
Phase Resistance: 0.99
Rotor Inertia (Kg.cm2): 42.5
Rated Current (A): 6.8
Weight (lbs): 45.19 lbs
Insulation Class: B
Insulation Resistance: 100 Mohm; 500V DC
Brand: Deelat Industrial
